* 18 models are compatible with HDR-FX7, HDR-FX7E, HVR-V1J, HVR-V1U, HVR-V1E, HVR-V1N


Click camera for actual comparison images.







The lens shade will cut an unwanted light beam, and it prevents flare and ghost image effect considerably.
HDP-9000EX High Definition
Telephoto conversion Lens 1.8x

Especially developed for using with a large aperture taking lens of High Definition camera, extending the focal length 1.8 times. Brings a distant subject up very close in maintaining the original superb image quality.
HDP-9000EX lens is originally designed in high resolution formula getting an amazing 280 lines/mm resolution power at center. It perfectly suits to a high definition camera.
The lens comes with an originally made Lens Shade which shuts a flare and ghost image effect considerably and the lens case. These are packed with the lens in the carton together.
HDP-9000EX extends the focal length of HDR-FX7 and HVR-V1 camera lens to 1340mm super telephoto*.
With the HDP-9000EX lens attached, there will be no influence on F number of the master lens.
Model RA7262 Raynox adapter ring(sold separately) for 62mm filter size is required for use with the HDP-9000EX + HDR-FX7/HVR-V1 cameras.

RA7262 adapter ring is Not included.
*35mm film equivalent.

Construction: Sturdy and solid metal body
(except the Lens Shade)
Magnification: Nominal 1.8x
Actual 1.8x/Diagonal, 1.8x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 3m
Effective zooming without vignetting: 5x - 20x zoom(16:9 mode)
Front filter size: 108mm
Mounting threads: 72mm
Size/Weight: 210 x 120mm/825g(29oz)
(including the Lens Shade)

Accessories included: Lens Shade, Lens caps, Lens case.

Specifications

PAGE TOP




Click camera for actual comparison images.





 Raynox lens shade: model LS-082
Weight: 69g.(2.4oz)


DCR-2025PRO 2.2x
High Definition Telephoto Conversion Lens

DCR-2025PRO lens extends the focal length of SONY HDR-FX7/HVR-V1 zoom lens to 1645mm Super telephoto !*
It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula. 260 lines/mm resolution power at center (MTF30%)
This model is made for 62mm direct mounting size.
*35mm film equivalent.
Magnification: Nominal 2.2x
Actual 2.2x/Diagonal, 2.2x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 4m
Effective zooming without vignetting: 10x - 20x zoom(16:9 mode)
Front filter size: 82mm
Mounting threads: 62mm
Size/Weight: 123 x 86mm/275g(9.7oz)

Accessories included: LS-082 lens shade, Lens caps, Lens pouch, 4-adapter rings 43mm/52mm/55mm/58mm filter size.

Specifications


The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably.
PAGE TOP




Click camera for actual comparison images.


DCR-1542PRO/DCR-1541PRO 1.54x
HD Telephoto Conversion Lens

DCR-1542PRO/DCR-1541PRO lens extends the focal length of SONY HDR-FX7/HVR-V1 zoom lens to 1150mm telephoto lens!*
It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula.
This new concept in designing the lens made it possible to achieve an amazing high definition telephoto lens of the 340 lines/mm resolution power at center (MTF30%), low dispersion and the increased light transmittance at fringe area.
It is necessary to mount RA5262A adapter ring (sold separately) for 62mm filter size is requiredwhen mounting the lens on the HDR-FX7/HVR-V1 cameras.
There is no difference in the quality of lens between DCR-1542PRO, DCR-1541PRO and DCR-1540PRO.
RA5262A adapter ring is Not Included.
*35mm film equivalent.
Magnification: Nominal 1.54x
Actual 1.54x/Diagonal, 1.54x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 2.5m
Effective zooming without vignetting: 5x - 20x zoom(16:9 mode)
Front filter size: 67mm
Mounting threads: 52mm
Size/Weight: 67 x 71mm/240g(8.5oz)
Accessories included in DCR-1542PRO : 3-Adapter rings 37mm/43mm/46mm filter size, Lens pouch, Lens caps, Instruction manuals.
Accessories included in DCR-1541PRO : 3-Adapter rings 37mm/43mm/55mm filter size, Lens pouch, Lens caps, Instruction manuals.
Specifications
PAGE TOP





Click camera for actual comparison images.





Selfmade Paper Lens Shade-by-Print
HDP-6000EX High Definition
Wideangle conversion Lens 0.79x

Production discontinued - Feb. 2013
New HDP-6000EX 0.79x high definition lens is especially designed for Professional High Definition Camcorders. It maintains sharp focusing while zooming thru the whole zoom range.
The lens creates super wide angle view of f=29mm (35mm film equiv.), compatible up to 20x zooming position when mounted on the SONY HDR-FX7/HVR-V1. HDP-6000EX lens controls the image distortion percentage at the least, less than -2.4%. The lens has an amazing resolution power of 640 lines/mm at center (MTF 30%) to suit the high definition image quality of the camera.
Model RA7262 Raynox adapter ring(sold separately) for 62mm filter size is required for use with the HDP-6000EX + HDR-FX7/HVR-V1 cameras.
Construction: Sturdy and solid metal body
Magnification: Nominal 0.79x
Actual 0.788x/Diagonal, 0.788x/Horizontal
Lens construction: 3G/4E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 20x zoom
Front filter size: 117mm
Mounting threads: 72mm
Size/Weight: 56 x 120mm/485g(17.1oz)

Accessories included: Lens caps, Lens case.
Specifications

PAGE TOP



HDP-5072EX High Definition
Semi-Fisheye conversion Lens 0.5x
The model HDP-5072EX is a 0.5x semi-fish eye conversion lens particularly designed for use with the High Definition large aperture camera lens, and it has a resolution power of 630 lines/mm at center (MTF30%). With the HDP-5072EX lens mounted on a High Definition camera's lens, it broadens 100% more the field of view than the original widest angle of view. In shooting a subject of short distance with HDP-5072EX lens on, it creates an interesting image of semi-fisheye effect, taking an advantage of the -31% distortion nature, but it takes a panoramic picture of 0.5x wide angle coverage without bothering the distortion image, when taken a distant subject.
Model RA7262 Raynox adapter ring(sold separately) for 62mm filter size is required for use with the HDP-5072EX + HDR-FX7/HVR-V1 cameras.
Construction: Sturdy and solid metal body
Magnification: Nominal 0.5x
Actual 0.44x/Diagonal, 0.5x/Horizontal
Lens construction: 3G/3E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 7x
Front filter size: None
Mounting threads: 72mm
Size/Weight: 42 x 125mm/640g(22.6oz)

Accessories included: Lens caps, Lens case.
Specifications




Click camera for actual comparison images.

HD-7062PRO High Definition
Wideangle Conversion Lens 0.7x

The model HD-7062PRO high definition Wideangle conversion lens is made of the high index optical glass with new concept of lens designing using a three-group/three-element lens formula. This new concept in designing the lens made it possible to achieve an amazing high definition wideangle lens of 540 lines/mm resolution power at center (MTF30%).
It's compatible with whole zoom area and stays in focus**.

**The lens is made compatible in using with a 20x zoom lens. However, when zoomed up to the end of the telephoto with the lens on, the image quality of the picture will be lowered except the center area, and the deterioration of resolution power at corners will occur.
This model is made for 62mm direct mounting size.
Magnification: Nominal 0.7x
Actual 0.7x/Diagonal, 0.7x/Horizontal
Lens construction: 3G/3E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 20x zoom**
Front filter size: 82mm
Mounting threads: 62mm
Size/Weight: 43 x 86mm/318g(11oz)

Accessories included: Lens caps, Lens pouch.

Specifications
PAGE TOP






Click camera for actual comparison images.


DCR-732/DCR-731 Wideangle Conversion Lens 0.7x
DCR-732/DCR-731 lens broadens an angle of view 37% more than the original camera lens gets. The lens is made of high index optical glass elements which obtain the maximum resolution power of 375 lines/mm at center (MTF30%), It's compatible with whole zoom area and stays in focus.
Model RA5262A Raynox adapter ring(sold separately) for 62mm filter size is required for use with the DCR-730 + HDR-FX7/HVR-V1 cameras.
RA5262A adapter ring is Not Included.

**The lens is made compatible in using with a 20x zoom lens. However, when zoomed up to the end of the telephoto with the lens on, the image quality of the picture will be lowered except the center area, and the deterioration of resolution power at corners will occur.
Magnification: Nominal 0.7x
Actual 0.71x/Diagonal, 0.75x/Horizontal
Lens construction: 2G/2E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 20x zoom(16:9 mode)**
Front filter size: None
Mounting threads: 52mm
Size/Weight: 29 x 66mm/130g(4.6oz)
Accessories included in DCR-732: 3-Adapter rings, Lens pouch, Lens caps, Instruction manuals.
Accessories included in DCR-731: 3-Adapter rings, Lens pouch, Lens caps, Instruction manuals.

Specifications
PAGE TOP







Click camera for actual comparison images.


DCR-FE181PRO High Definition
Diagonal Fisheye Conversion Lens
Shooting a creative image or making the ultra wideangle picture ? The DCR-FE181PRO lens captures an amazing wideangle view. 480 lines/mm resolution power at center (MTF30%)
This model is 62mm direct mounting size.


Note: The lens is designed to perform an optimum capacity when used at the zoom range from the widest angle point to 3x ratio. Beyond the 3x toward telephoto, it starts losing the image quality at corners.
Slight vignetting may occur in (under scanning) mode and still image mode in maximum wideangle zooming.
Magnification: Nominal 0.24x
Actual 180 degrees/Diagonal, 138 degrees/Horizontal,75 degrees/Vertical (taken at 16:9 Wide mode)
Lens construction: 4G/5E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 3x zoom(16:9 mode)
Front filter size: None
Mounting threads: 62mm
Size/Weight: 68 x 100mm/685g(24oz)

Accessories included: Lens caps, Lens pouch, 4-adapter rings 43mm/52mm/55mm/58mm filter size.
Specifications
PAGE TOP




Click camera for actual comparison images.


DCR-CF187PRO High Definition
Circular Fisheye Conversion Lens

Upon mounting on the zoom lens, it opens the field of view to the ultra wide angle.
This model is 62mm direct mounting size.

Important notice: DCR-CF187PRO may not produce either circular or full frame diagonal fish-eye image when mounted on HDR-FX7/HVR-V1 HDV camcorders as shown in our comparison image page.

There is no difference in the quality of lens between DCR-CF187PRO and DCR-CF185PRO.
Magnification: Nominal 185degrees
Actual 185degrees/Horizontal
Lens construction: 4G/6E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 12x zoom(16:9 mode),
Front filter size: None
Mounting threads: 62mm
Size/Weight: 98 x 96mm/560g(20oz)

Accessories included: Lens caps, Lens pouch, 4-adapter rings 43mm/52mm/55mm/58mm filter size.

Specifications
PAGE TOP




Click camera for actual comparison images
.

WMV FILE 6500KB
MPEG-4 3000KB
MX-3062PRO
Semi-Fisheye Ultra-Wideangle Lens Attachment, 0.3x

MX-3062PRO lens is specially designed to fit on SONY HDR-FX7/HVR-V1's 62mm filter threads directly.
The lens provides an extra wideangle view.

* Compatible with HDR-FX7, HDR-FX7E, HVR-V1J, HVR-V1U, HVR-V1E, HVR-V1N HDV camcorders.
This model is made for 62mm direct mounting size.

MX-3062PRO is designed to focus when the zoom lens is set in 1-4x wideangle position.
Magnification: Nominal 0.3x
Actual 0.25x/Diagonal, 0.35x/Horizontal
Lens construction: 1G/1E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 4x zoom
Front filter size: 87mm
Mounting threads: 62mm
Size/Weight: 25 x 95mm/205g(7.2oz)

Accessories included: Lens caps, Lens pouch.
Specifications

PAGE TOP




Click camera for actual comparison images.


WMV FILE 9800KB
MPEG-4 5300KB
DCR-5000 Super Wideangle Lens Attachment, 0.5x
Production discontinued - July 2008
DCR-5000 lens broadens angle of view 100% more than original camera lens.

* Compatible with HDR-FX7, HDR-FX7E, HVR-V1J, HVR-V1U, HVR-V1E, HVR-V1N HDV camcorders.
Model RA5262A Raynox adapter ring(sold separately) for 62mm filter size is required for use with the DCR-5000 + HDR-FX7/HVR-V1 cameras.
RA5262A adapter ring is Not Included.
Magnification: Nominal 0.5x
Actual 0.5x/Horizontal, 0.44x/Diagonal
(Limited zoom capability)
Lens construction: coated single glass element
Front filter size: None
Mounting threads: 52mm
Size/Weight: 26 x 90mm/140g(4.9oz)

Accessories included: Lens caps, Lens pouch.

DCR-5000 is designed to focus when the zoom lens is set in 1-4x wideangle position.
PAGE TOP





Click camera for actual comparison images.

WMV FILE 9800KB
MPEG-4 5300KB

XL-3000PRO Semi-Fisheye Ultra-Wideangle Lens Attachment, 0.3x
XL-3000PRO lens is equipped with a Lens Shade and universal sized Snap-on mount, and attaches instantly to your Camcorders lens to provide an extra wideangle view.
Universal mount is suitable for 52-67mm filter sizes.
* Compatible with HDR-FX7, HDR-FX7E, HVR-V1J, HVR-V1U, HVR-V1E, HVR-V1N HDV camcorders.
Magnification: Nominal 0.3x
Actual 0.35x/Horizontal, 0.25x/Diagonal
(Limited zoom capability)
Lens construction: coated single glass element
Front filter size: None
Mounting threads: 52-67mm
Size/Weight: 24 x 135mm/175g(6.17oz)

Accessories included: Lens caps, Lens pouch.

XL-3000PRO is designed to focus when the zoom lens is set in 1-4x wideangle position.
PAGE TOP




Click camera for actual comparison images.


WMV FILE 9800KB
MPEG-4 5300KB
XL-5000PRO Super Wideangle Lens Attachment, 0.5x
XL-5000PRO lens is equipped with a Lens Shade and universal sized Snap-on mount, and attaches instantly to your Camcorders lens to provide an extra wideangle view.
Universal mount is suitable for 52-67mm filter sizes.
* Compatible with HDR-FX7, HDR-FX7E, HVR-V1J, HVR-V1U, HVR-V1E, HVR-V1N HDV camcorders.
Magnification: Nominal 0.5x
Actual 0.5x/Horizontal, 0.44x/Diagonal
(Limited zoom capability)
Lens construction: coated single glass element
Front filter size: None
Mounting threads: 52-67mm
Size/Weight: 24 x 135mm/140g(4.94oz)

Accessories included: Lens caps, Lens pouch.

XL-5000PRO is designed to focus when the zoom lens is set in 1-4x wideangle position.
PAGE TOP




Click camera for actual comparison images.


WMV FILE 9800KB
MPEG-4 5300KB

XL-7000PRO Wideangle Lens Attachment, 0.7x
XL-7000PRO lens is equipped with a Lens Shade and universal sized Snap-on mount, and attaches instantly to your Camcorders lens to provide an extra wideangle view.
Universal mount is suitable for 52-67mm filter sizes.
* Compatible with HDR-FX7, HDR-FX7E, HVR-V1J, HVR-V1U, HVR-V1E, HVR-V1N HDV camcorders.
Magnification: Nominal 0.7x
Actual 0.7x/Horizontal, 0.68x/Diagonal
(Limited zoom capability)
Lens construction: coated single glass element
Front filter size: None
Mounting threads: 52-67mm
Size/Weight: 24 x 135mm/93g(3.28oz)

Accessories included: Lens caps, Lens pouch.

XL-7000PRO is designed to focus when the zoom lens is set in 1-4x wideangle position.
PAGE TOP





Click camera for actual comparison images.




DCR-5320PRO 3-in-1
High Definition Macro Conversion Lens

The DCR-5320PRO High Definition Macro Conversion lens is particularly designed to use with the high-end digital, film and High Definition cameras, resulting in an amazing resolution power of 200 lines/mm at center (MTF30%) with a low dispersion. With the Macro lens attached on the camera's lens, it makes possible to approach the object very close for macro shooting. The model consists of two independent lenses, one is with 2-diopter magnification and the other with 3-diopter. It also makes a 5-diopter lens by coupling the both lenses together. Taking advantage of using in three ways, you can shoot the object at the distances of either 50cm or 30cm or 17cm, depending upon the nature of a subject. All lens glass elements are fully coated for the optimum light transmittance and fine image quality.
Model RA7262 Raynox adapter ring(sold separately) for 62mm filter size is required for use with the DCR-5320PRO + HDR-FX7/HVR-V1 cameras.
LENS 2-Diopter 3-Diopter 5-Diopter
Construction 1G/2E 2G/3E 3G/5E
Weight 105g(3.7oz) 290g(10.2oz) 395g(13.9oz)
Length 24mm 39mm 59mm
Filter size 72mm 72mm 72mm
Mount size 72mm 72mm 72mm
Focusing Distance 486mm* 311mm* 170mm*
Zooming capability 1x-20x (16:9) 1x-20x (16:9) 1.5x-20x (16:9)
* Camera focus set in infinity ∞.
* In under scanning mode.
* Distances shown here are between top of lens to the object.
* All surfaces fully coated
Accessories included: Lens caps, Lens pouch, Instructions.
Specifications

How ?
Add one more DCR-5320PRO onto the same set, giving you
8 different diopter choice of 2, 3, 4, 5, 6, 7, 8 and 10.
PAGE TOP




Click camera for actual comparison images.

DCR-150 Macro Conversion Lens
You can simply "Snap On" DCR-150 Macro lens onto the SONY HDR-FX7/HVR-V1's 62mm filter threads directly. The shooting distance to the object is about 210mm and the picture size would be 9.6mm width in Tape recoding mode.


Specifications
Magnification: 4.8-Diopter
Lens construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 6x - 20x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/50g(1.8oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.
PAGE TOP




Click camera for actual comparison images.


DCR-250 High Power Macro Conversion Lens
You can simply "Snap On" DCR-250 Macro lens onto the SONY HDR-FX7/HVR-V1's 62mm filter threads directly. The shooting distance to the object is about 109mm and the picture size would be 6mm width in Tape recoding mode.



Specifications

Magnification: 8-Diopter
Lens Construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 6x - 20x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/60g(2.1oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.

PAGE TOP




Click camera for actual comparison images.


WMV FILE 8900KB
MPEG-4 8400KB
MSN-202 Super Macro Conversion Lens
The combination of MSN-202 and SONY HDR-FX7/HVR-V1 display panel makes it easy to capture a tiny object from the distance of 32mm to the object at maximum telephoto position.
Magnification: 25-Diopter
Lens construction: 3G/4E Optical coated glass elements
Image size: 1.9mm width
Effective zooming without vignetting: 12x - 20x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 22 x 42mm/60g(2.1oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
PAGE TOP




Click camera for actual comparison images.


WMV FILE 8900KB
MPEG-4 8400KB

MSN-505 Super Macro Conversion Lens
With MSN-505 Super Macro lens attached, the camera captures an intricate tiny object like 2mm width for a frame-filling enlarged close-up image from the distance of 18.5mm to the object at the maximum telephoto position.
Magnification: 32-Diopter
Lens construction: 3G/4E Optical coated glass elements
Image size : 1.4mm width
Effective zooming without vignetting: 18x - 20x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 26 x 42mm/86g(3oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
PAGE TOP

The cosmetic design may change without a prior notice.
There will be no reduction of light value(F-number) when these conversion lenses are attached on the camera's lens(Except DCR-5320PRO, DCR-150, DCR-250, MSN-202 and MSN-505 macro lenses.)
Depending upon the condition of shooting, especially when the lighting is not bright enough, there may be possibility of creating a flare effect which reduces the image quality. When the conversion lens is attached, please make sure that the object is under the bright condition.
Raynox telephoto conversion lenses are designed to use at maximum Telephoto position of  camera's zoom lens, unless specified otherwise.
Raynox wideangle conversion lenses are designed to use at maximum wideangle position of  camera's zoom lens unless specified otherwise.
HD-7062PRO lens is made compatible in using with a 20x zoom lens. However, when zoomed up to the end of the telephoto with the lens on, the image quality of the picture will be lowered except the center area, and the deterioration of resolution power at corners will occur. You can see the actual degree of deteriorated image on the reference picture in our RAYNOX home page. When shooting with a 20-time zoom lens at the telephoto side, please select the bright area of enough lighting. When you are using the wide-angle lens on the zoom lens set at the telephoto end frequently, it's suggested to use our professional wide angle model RAYNOX HDP-6000EX(72mm mounting thread), .
Remote control function may not work properly with conversion lens attached.
Internal video light/flash may not function with conversion lens or filter attached.
Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image.
The lens is neither made for dust-free nor moisture/water-proof.
All of Raynox conversion lenses are proudly made in Japan. At our wholly owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.
FOR DIGITAL CAMERA FOR VIDEO CAMCORDER MACRO LENS FOR SLR CAMERA PROJECTION LENS ABOUT US
WORLDWIDE CONTACT ENGLISH INDEX HOME

RAYNOX is the registered trademark of Yoshida Industry Co., Ltd. Tokyo. Other brand names and the models are the trademarks of their manufactures or their subsidiaries and may be registered in certain jurisdictions. ©Y.I.C.
