* 8 models are compatible with SONY HDR-FX1000, FX1000E, AX2000, AX2000E, HVR-Z5E, HVR-Z5U, HXR-NX5U, NX5E, HXR-NX3 HD Camcorders.
Click camera for actual comparison images.
HDP-9000EX High Definition Telephoto conversion Lens 1.8x
Especially developed for using with a large aperture taking lens of High
Definition camera, extending the focal length 1.8 times. Brings a distant subject
up very close in maintaining the original superb image quality.
HDP-9000EX lens is originally designed in high resolution formula getting
an amazing 280 L/mm resolution power at center. It perfectly suits to a high definition camera.
The lens comes with an originally made Lens Shade which shuts a flare and
ghost image effect considerably and the lens case. These are packed with
the lens in the carton together.
HDP-9000EX extends the focal length of HDR-FX1000, FX1000E, AX2000, AX2000E, HVR-Z5E, HVR-Z5U, HXR-NX5U, NX5E 20x zoom lens to
1062mm* telephoto and f=1037mm* for HXR-NX3. *35mm film equivalent.
With the HDP-9000EX lens attached, there will be no influence on F number
of the master lens. This model is made for 72mm direct mounting size.
Construction: Sturdy and solid metal body
(excluding the Lens Shade)
Magnification:
Nominal 1.8x
Actual 1.8x/Diagonal, 1.8x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 2.5m
Effective zooming without vignetting: 9x - 20x zoom
Front filter size: 108mm
Mounting threads: 72mm
Size/Weight: 210 x 120mm/825g(29oz)
(including the Lens Shade)
Accessories included: Lens Shade, Lens caps,Lens case. Specifications
The lens shade will cut an unwanted light beam,
and it reduces flare and ghost image effect considerably.
HDP-6000EX High Definition
Wideangle conversion Lens 0.79x Production discontinued - Feb. 2013
New HDP-6000EX 0.79x high definition lens is especially designed for Professional
High Definition Camcorders. It maintains clear focusing while zooming whole
zoom range.
The lens creates super wide angle view of f=23.3mm (35mm film equiv.16:9 mode),
compatible up to 20x zooming position when mounted on the HDR-FX1000, FX1000E, AX2000, AX2000E, HVR-Z5E, HVR-Z5U, HXR-NX5U, NX5E, HXR-NX3 20x zoom lens. HDP-6000EX lens controls the image distortion percentage at the least, less than -2.4%. The lens has an amazing resolution power of 640 lines/mm at center (MTF 30%) to suit the high definition image quality of the camera. This model is made for 72mm direct mounting size.
Construction: Sturdy and solid metal body
Magnification:
Nominal 0.79x
Actual 0.788x/Diagonal, 0.788x/Horizontal
Lens construction: 3G/4E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 20x zoom
Front filter size: 117mm
Mounting threads: 72mm
Size/Weight: 56 x 120mm/485g(17.1oz)
HDP-5072EX High Definition
Semi-Fisheye conversion Lens 0.5x
The model HDP-5072EX is a 0.5x semi-fish eye conversion lens particularly designed for use with the High Definition large aperture camera lens, and it has a resolution power of 630 lines/mm at
center (MTF30%). With the HDP-5072EX lens mounted on a High Definition camera's lens, it broadens 100% more the field of view than the original widest angle of view. In shooting a subject of short distance with HDP-5072EX lens on, it creates an interesting image of semi-fisheye effect, taking an advantage of the -31% distortion nature, but it takes a panoramic picture of 0.5x wide angle coverage without bothering the distortion image, when taken a distant subject.
Construction: Sturdy and solid metal body
Magnification:
Nominal 0.5x
Actual 0.44x/Diagonal, 0.5x/Horizontal
Lens construction: 3G/3E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 10x zoom
Front filter size: None
Mounting threads: 72mm
Size/Weight: 42 x 125mm/640g(22.6oz)
Upon mounting on the zoom lens, The DCR-CF187PRO opens the field of view
to the circular fisheye image. It's a completely new high definition lens
made of the high index optical coated lens with a 4-group/6-element formula to obtain the maximum resolution power of 500 lines/mm at center (MTF30%), while it has low dispersion. Raynox Model **RA6272(sold separately) adapter ring is required
for use with the DCR-CF187PRO + SONY HDR-FX1000, FX1000E, AX2000, AX2000E, HVR-Z5E, HVR-Z5U, HXR-NX5U, NX5E, HXR-NX3 HD Camcorders. **The original mounting threads of this lens is 62mm, and it can be mounted onto the HDR-FX1000, AX2000, HVR-Z5J, HXR-NX5J, HXR-NX3 cameras by using the RA6272 adapter ring
sold separately. However, this particular adapter ring used with above cameras may stick on and not be detached after use. For using the Adapter Ring RA6272 properly in this case,
we suggest that the adapter ring to be mounted on DCR-CF187PRO lens permanently first by using an instant adhesive available on the market. WARNING….Please note that it's impossible the lens once fixed with the adapter ring permanently to be back to the original DCR-CF187PRO lens mounting threads.
A Circular Fisheye image can be displayed at still picture mode and in under-scanning system(PC monitor) .
Magnification: Nominal 185-degree
Actual 185-degree/Diagonal, 185-degree/Horizontal
Lens construction: 4G/6EOptical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x zoom(Max.Wideangle )
Front filter size: None
Mounting threads: 62mm
Size/Weight: 98 x 96mm/560g(20oz)
Click camera for actual comparison images.
How ?
Add one more DCR-5320PRO onto the same set, giving you
8 different diopter choice of 2, 3, 4, 5, 6, 7, 8 and 10.
DCR-5320PRO 3-in-1
High Definition Macro Conversion Lens
The DCR-5320PRO High Definition Macro Conversion lens is particularly designed
to use with the high-end digital, film and High Definition camcorders, resulting
in an amazing resolution power of 200 lines/mm at center (MTF30%) with a low dispersion. With the Macro lens attached on the camera's lens,
it makes possible to approach the object very close for macro shooting.
The model consists of two independent lenses, one is with 2-diopter magnification
and the other with 3-diopter. It also makes a 5-diopter lens by coupling the both lenses together. Taking advantage of using in three ways, you
can shoot the object at the distances of either 50cm or 30cm or 17cm, depending
upon the nature of a subject. All lens glass elements are fully coated
for the optimum light transmittance and fine image quality.
The adapter rings which fit to the 52mm, 55ｍｍ, 58mm, 62mm, 67mm, 77mm,
82mm threads (except 72mm) are sold separately. This model is made for 72mm direct mounting size.
LENS
2-Diopter
3-Diopter
5-Diopter
Construction
1G/2E
2G/3E
3G/5E
Weight
105g
290g
395g
Length
24mm
39mm
59mm
Filter size
72mm
72mm
72mm
Mount size
72mm
72mm
72mm
Focusing Distance
486mm*
311mm*
170mm*
Zooming capability
1x-20x (16:9)
2x-20x (16:9)
3x-20x (16:9)
* Camera focus set in infinity ∞.
* Distances shown here are between top of lens to the object.
Accessories included: Lens caps, Lens case, Instructions. All surfaces fully coated
With RA4372A Adapter Ring, the lens to be mounted into the camera's lens,
set at the telephoto position. The shooting distance to the object is about
210mm and be able to capture 12.5mm x 7mm size object in full frame.
When using the RA4372A Adapter Ring, the bundled Universal Adapter can
not be used. When using the Universal Adapter please use RA6272 Adapter
Ring instead of RA4372A. Specifications
Magnification: 4.8-Diopter
Lens construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 15x - 20x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/50g(1.8oz)
Capture and view the microscopic world all around you with this Super Macro
DCR-250 lens! It's a suitable device to create the original DTP materials.
Also, it takes picture of a tiny logo or icon on name card or small printed
materials. The lens is designed to use with the RA4372A Adapter Ring attached
and set the camera's lens at telephoto position. The shooting distance
to the object is about 109mm andbe able to capture 7.55mm x 4.3mm size object in full frame.
When using the RA4372A Adapter Ring, the bundled Universal Adapter can
not be used. For using the Universal Adapter please use RA6272 Adapter
Ring instead of RA4372A. Specifications
Magnification: 8-Diopter
Lens Construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 15x -20x zoom
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/60g(2.1oz)
The lens is required to use with *RA3772A Adapter Ring attached. Then, mount
it onto the Camera's zoom lens, set at the max. telephoto zooming. It is designed
to have a shooting distance
of 32mm to the subject so that it will have a proper lighting inlet and
the ultra macro photo of 2.5 x 1.4mm picture frame.
Note: It may create the darkened corners on the picture taken even at the
maximum telephoto position of the zoom lens. *RA3772A has been discontinued its production in April 2009 and available quantity may be limited.
Magnification: 25-Diopter
Lens construction: 3G/4E Optical coated glass elements.
Effective zooming without vignetting: 20x (Max.Telephoto )
Mounting threads: 37mm
Front filter size: None
Size/Weight: 22 x 42mm/60g(2.1oz)
The original Lens Shade can be attached on the camera lens with the PFR-072MC
filter on.
The PFR-072MC filter is made for attaching permanently with SONY HDR-FX1000, FX1000E, AX2000, AX2000E, HVR-Z5E, HVR-Z5U, HXR-NX5U, NX5E, HXR-NX3 HVR Camcorders., protecting the expensive zoom lenses from dust, dirt and accidental damage.
The filter is made of high grade optical glass multi-layer coated for a
maximum high fidelity to the original characteristic of the camera lens.
A filter cap is included in the set.
● The cosmetic designs may change without prior notice. ●Remote control function may not work properly with conversion lens attached. ●The HDP-9000EX lens is rather heavy stuff and may limit the way of shooting condition. Be
careful in handling the camera with the lens attached, such as supporting
or protecting the lens by your own hand at all time while shooting images. ● There will be no reduction of light value(F-number) when these conversion lenses
are attached on the camera's lens(Except DCR-5320PRO, DCR-150, DCR-250, MSN-202 and MSN-505
macro lenses.) ● Depending upon the condition of shooting, especially when the lighting
is not bright enough, there may be possibility of creating a flare effect
which reduces the image quality. When the conversion lens is attached,
please make sure that the object is under the bright condition. ● Raynox telephoto conversion lenses are designed to use at maximum Telephoto
position of camera's zoom lens, unless specified otherwise. ● Raynox wideangle conversion lenses are designed to use at maximum wideangle
position of camera's zoom lens unless specified otherwise. ● Raynox fisheye conversion lenses were designed to use at maximum wideangle
position of camera's zoom lens unless specified. ● Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image. ● All of Raynox conversion lenses are proudly made in Japan. At our owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality. ● The lens is neither made for dust-free nor moisture/water-proof.
