Click camera for actual comparison images.
DCR-2020PRO 2.2x High Definition
Super Telephoto Conversion Lens

DCR-2020PRO lens extends the focal length of FUJIFILM FinePix S5200/S5600 camera zoom lens to over 830mm Super telephoto ! (35mm film equivalent) It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula.
260 lines/mm resolution power at center (MTF30%)

Model RA6255 Raynox adapter ring for 55mm filter size is required for use with the DCR-2020PRO + FinePix S5200/S5600 camera.

Magnification: Nominal 2.2x Actual 2.2x / Diagonal, 2.2x / Horizontal
Minimum focusing distance: 9m/4m in macro mode
Zoom capability: f=63mm-f=45mm
Lens construction: 2G/4E Optical coated glass elements
Mounting threads: 62mm
Front filter size: 82mm
Size/Weight: 123 x 85mm/275g.(9.7oz)
RA6255 adapter ring is Not Included.
RA6258 and RA6252 adapter rings are Included.
Specifications







Click camera for actual comparison images.




Click camera for actual comparison images.

DCR-CF187PRO High Definition 185º Circular Fish-Eye Conversion Lens

Upon mounting on the zoom lens, the DCR-CF187PRO opens the field of view to the circular fisheye image, ultra wide angle, the diagonal fisheye angle images. It's a completely new high definition lens made of the high index optical coated lens with a 4-group/6-element formula to obtain the maximum resolution power of 500 lines/mm at center (MTF30%), while it has low dispersion.

Model RA6255 adapter ring is required for use with the DCR-CF187PRO + FinePix S5200/S5600 camera.
Magnification: Nominal 185-degree, Actual 185-degree/Diagonal, 185-degree/Horizontal
Minimum focusing distance: 30mm
Zoom capability: f=40mm-f=6.3mm
Lens construction: 4G/6E, made of optical glass lenses, all surfaces fully coated.
Mounting threads: 62mm
Size / Weight: 96 x 98 / 560g(20oz)

RA6243, RA6255, RA6252 and RA6258 adapter rings are Included.
Specifications
DCR-FE181PRO Pro Fish-Eye(Full Frame) Lens

DCR-FE181PRO lens captures an amazing diagonal fisheye view. It's a completely new high definition lens made of the high index optical lens with a 4-group/5-element formula.
Model RA6255 adapter ring is required for use with the DCR-FE181PRO + FinePix S5200/S5600 camera.

Magnification: Nominal 0.24x Actual 180-degree/Diagonal, 0.24x/Horizontal
Minimum focusing distance: 30mm
Zoom capability: f=31.5mm-f=6.3mm

Lens construction: 4G/5E Optical coated glass elements
Mounting threads: 62mm
Front filter size: None
Size/Weight: 100 x 69mm/685g(24oz)

RA6243, RA6255, RA6252 and RA6258 adapter rings are Included.
Unable to capture 180º angle of view on diagonal line.
Specifications


Video Clip
WMV VIDEO FILE(WMV 700KB)(700KB)
MOV VIDEO FILE(MOV 3800KB)(3800KB)




Click camera for actual comparison images.




Click camera for actual comparison images.
DCR-6600PRO High Definition Wideangle lens 0.66x

The lens creates super wide angle view of f=25mm (35mm film equiv.), compatible up to 5x zooming range. DCR-6600PRO lens controls the image distortion percentage at the least, less than -1.3%.
Model RA5255B adapter ring is required for use with the DCR-6600PRO + FinePix S5200/S5600 camera.
Magnification: Nominal 0.66x Actual 0.66x/Diagonal, 0.66x/Horizontal
Minimum focusing distance: 30mm
Zoom capability: f=31.5mm-f=6.3mm

Lens construction: 3G/3E Optical coated glass elements
Mounting threads: 52mm
Front filter size: 72mm
Size/Weight:: 77 x 40mm/178g

RA5255B adapter ring is Not Included.
Specifications

It is recommended to use the combination of DCR-6600PRO with RA5255B on S5600 camera than using HD-6600PRO-55 Wideangle conversion lens alone.(Please see the image comparison.)
DCR-730 Wideangle lens 0.7x

DCR-730 lens broadens angle of view 37% more than original camera lens. The lens is made of high index optical glass elements which obtain the maximum resolution power of 375 lines/mm at center (MTF30%),
There will be no reduction of light value when this conversion lens is attached on the camera's lens.
Model RA5255B adapter ring is required for use with the DCR-730 + FinePix S5200/S5600 camera.
Magnification: Nominal 0.7x Actual 0.71x/Diagonal, 0.75x/Horizontal
Minimum focusing distance: 30mm/(1.2M at f=63mm)
Zoom capability: f=63mm-f=6.3mm

Lens construction: 2G/2E Optical coated glass elements
Mounting threads: 52mm
Size/Weight:: 66 x 29mm/130g

RA5255B adapter ring is Not Included.
Specifications



Click camera for actual comparison images.




Click camera for actual comparison images.
MDR-079PRO 0.79x
High Definition Wideangle Conversion Lens


MDR-079PRO 0.79x high definition lens is especially designed for getting low distortion(-1.9%) and high resolution(330 lines/mm resolution power at center (MTF30%)) performance. The lens converts the camera into the superb 30mm(35mm film equivalent) wide angle coverage one.

Model RA5255B adapter ring and RA4952 adapter ring are required for use with the MDR-079PRO + FinePix S5200/S5600 camera..
Magnification: Nominal 0.79x Actual 0.79x / Diagonal, 0.79x / Horizontal
Minimum focusing distance: 30mm
Zoom capability: f=12.6mm-f=6.3mm

Lens construction: 3G/3E Optical coated glass elements
Mounting threads: 49mm
Front filter size: 82mm
Size/Weight: 86 x 29mm/195g.(6.8oz)
RA4952 adapter ring is Included.
RA5255B adapter ring is Not Included.

Production Discontinued.
Available quantity may be limited. (Sep. 2007)
DCR-5000 Super Wideangle lens 0.5x
Production discontinued - July 2008
The lens creates 0.5x Super wide angle view.
(f=19mm-35mm film equiv.)

Model RA5255B adapter ring is required for use with the DCR-5000 + FinePix S5200/S5600 camera.
Magnification: Nominal 0.5x Actual 0.44x/Diagonal, 0.5x/Horizontal
Minimum focusing distance: 30mm
Zoom capability: f=6.3mm
only
Lens construction: 1G/1E Optical coated glass element
Mounting threads: 52mm
Front filter size: None
Size/Weight:: 90x26mm/140g
Specifications
RA5255B adapter ring is Not Included.

DCR-5000 is designed to focus properly when the camera is set in maximum wide & macro mode,s-macro, manual mode.



Click camera for actual comparison images.



Click camera for actual comparison images.
HD-7000PRO Wideangle lens 0.7x

The model HD-7000PRO high definition Wideangle conversion lens is made of the high index optical glass with new concept of lens designing using three-group/three-element lens formula. This new concept in designing the lens made it possible to achieve an amazing high definition wideangle lens of 540 lines/mm resolution power at center (MTF30%).

There will be no reduction of light value when this conversion lens is attached on the camera's lens.
Model RA5255B adapter ring Tube and RA5852 adapter ring are required for use with the HD-7000PRO.
Magnification: Nominal 0.7x Actual 0.7x/Diagonal, 0.7x/Horizontal
Minimum focusing distance: 30mm
Zoom capability: f=18.9mm-f=6.3mm

Lens construction: 3G/3E Optical coated glass elements
Mounting threads: 58mm
Front filter size: 82mm
Size/Weight:: 86 x 37mm/313g

RA5255B adapter ring is Not Included.
RA5852 adapter ring is Not Included.
Specifications

DCR-1542PRO 1.54x
High Definition Telephoto Conversion Lens

DCR-1542PRO lens extends the focal length of FUJIFILM FinePix S5200/S5600 camera lens to 585mm telephoto ! (35mm film equivalent) It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula.
340 lines/mm resolution power at center (MTF30%)

Magnification: Nominal 1.54x Actual 1.54x / Diagonal, 1.54x / Horizontal
Minimum focusing distance: 3.5m
Zoom capability: f=63mm-f=39mm
Lens construction: 2G/4E Optical coated glass elements
Mounting threads: 52mm
Front filter size: 67mm
Size/Weight: 71 x 67mm/240g
RA5255B adapter ring is Not Included.
RA5852 adapter ring is Not Included.

Specifications



Click camera for actual comparison images.



Click camera for actual comparison images.

DCR-150 Macro/Close-Up lens

You can simply "Snap On" DCR-150 Macro lens onto
FinePix S5200/S5600 camera (Shooting distance to the object 185mm)
Lens construction: 2G/3E Optical coated glass elements
Zoom capability: f=63mm-f=18mm
Magnification: 6.4x, compared to camera's max.wideangle
Front filter size: 49mm
Rear threads size: 43mm
Size/Weight: DCR-150 53x18mm/50g.
CAMERA STAND KS-2000 FOR MACRO IMAGING


Specifications


UAC2000 Universal adapter is Included.
DCR-250 Super Macro/Close-Up lens

You can simply "Snap On" DCR-250 Super Macro lens onto FinePix S5200/S5600 camera. (Shooting distance from the object 115mm)

Lens construction: 2G/3E Optical coated glass elements
Zoom capability: f=63mm-f=21mm
Magnification: 10x, compared to camera's max.wideangle
Front filter size: 49mm
Rear threads size: 43mm
Size/Weight: DCR-250 53x18mm/60g.
CAMERA STAND KS-2000 FOR MACRO IMAGING


Specifications


UAC2000 Universal adapter is Included.



Click camera for actual comparison images.



Click camera for actual comparison images.
MSN-202 Super Macro/Close-Up lens

You can simply "Snap On" MSN-202 Super Macro lens onto the FinePix S5200/S5600 camera by using a universal mount UAC3500 and it will be able to take macro images with minimum distortion at the maximum telephoto position of FinePix S5200/S5600 camera.
(Shooting distance from the object ;30mm in maximum telephoto mode.)
Magnification: 30x, compared to camera's max.wideangle macro image size.
Zoom capability: f=63mm-f=30mm
Lens construction: 3G/4E Optical coated glass elements.
Front filter size: None
Rear threads size: 37mm
Size/Weight: MSN-202 42x22mm/60g.
CAMERA STAND KS-2000 FOR MACRO IMAGING


UAC3500 Universal adapter is Included.
MSN-505 Super Macro/Close-Up lens

With MSN-505 Super Macro lens attached, the camera captures an intricate tiny object like 3.5mm x 2.6mm for a frame-filling enlarged close-up image from the distance of 18mm to the object at the maximum telephoto position.You can simply "Snap On" MSN-505 Super Macro lens onto the filter threads of FinePix S5200/S5600 camera by using a universal mount UAC3500 and it will be able to capture macro images with minimum distortion at the maximum telephoto position of FinePix S5200/S5600 camera.

Magnification: 40x, compared to camera's max.wideangle macro image size.
Zoom capability: f=63mm-f=39mm
Lens construction: 3G/4E Optical coated glass elements.
Front filter size: None
Rear threads size: 37mm
Size/Weight: MSN-505 42 x 24mm/86g.
CAMERA STAND KS-2000 FOR MACRO IMAGING


UAC3500 Universal adapter is Included.



CAMERA STAND KS-2000 FOR MACRO IMAGING
A camera stand with built-in light source and height adjustable camera mount.




WMV VIDEO FILE(WMV 480KB)
(480KB)
MOV VIDEO FILE(MOV 3400KB)
(3400KB)
WMV VIDEO FILE(WMV 600KB)
(600KB)
MOV VIDEO FILE(MOV 3600KB)
(3600KB)






RA6255B adapter ring

This is an adapter ring RA6255 required for mounting DCR-2025PRO, DCR-CF187PRO, DCR-FE181PRO. onto FinePix S5200/S5600 camera.
RA6255B adapter ring is included with the above mentioned Raynox conversion lenses.

F62-M55mm size adapter ring

RA5255B adapter ring

This is an adapter ring required for mounting DCR-1542PRO, DCR-5000,MDR-079PRO,HD-7000PRO, DCR-730 onto FinePix S5200/S5600 camera.


F52-M55mm size adapter ring

Do not use the built-in flash while the lens is attached.
The DCR-CF187PRO/DCR-FE180PRO lenses weigh 560g (1.24lbs)/685g (1.5 lbs)and they are rather heavy stuff and may limit the way of shooting condition.Be careful in handling the camera with the lens attached, such as supporting or protecting the lens by your own hand.
Raynox telephoto conversion lenses were designed to use at maximum Telephoto position of  camera's zoom lens.
Raynox wideangle conversion lenses were designed to use at maximum wideangle position of  camera's zoom lens unless specified.
All of Raynox conversion lenses are proudly made in Japan. At our wholly owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.
The production of MSN-200 & MSN-500 have been discontinued in Nov. 2005 and they were replaced by MSN-202 & MSN-505.
*You may need a adapter ring RA5255 for mounting DCR-1540PRO, DCR-6600PRO, DCR-730, DCR-5000, MDR-079PRO, HD-7000PRO lenses onto FinePix S5200/S5600 camera.
*The cosmetic designs may change without prior notice.
