-1.3% Super low distortion image !
|
Especially designed for use with high-end digital camera which incorporates
the CCD chip of more than mega-pixels, and the lens is made of hi-index
optical glasses, 3-group/3-element, fully coated for non-distortion(-1.3%)
and sharp images. It's an ideal accessory lens for professionals and advanced
amateurs shooting in tight place. There will be no reduction of light value when this conversion lens is attached on the camera's lens.
The original Raynox adapters are designed and made to suit the best physically
and optically to the DCR-6600PRO lens to obtain the optimum image quality
like the pictures shown in our website. When the adapters of other make
were used with Raynox DCR-6600PRO lens, the picture image quality could
be slightly deteriorated, especially around the corners.
DCR-6600PRO has been replaced by HD-6600PRO-52. There is no difference in the quality and product sizes of lens between DCR-6600PRO and HD-6600PRO-52.
|
Click the lens to comparison images
|
Center resolution power 350-line/mm
 |
Non-Distortion(-1.3%)
|
72mm front filter threads
|
|
| |
Specifications & Measurements |
| |
Magnification |
Nominal 0.66x
Actual 0.66x Diagonal, 0.66x Horizontal |
| |
Lens construction |
3-group/3-element, Coated optical glass elements |
| |
Image distortion |
-1.3%(max.wideangle) |
| |
Front Filter thread |
72mm |
| |
Mounting thread |
52mm |
| |
Dimensions |
39mm x 75mm |
| |
Weight |
178g(6.3oz) |
| |
Accessories |
Lens case, Lens caps, Instruction manuals |
| |
|
|
|
Compatible with 4K/HD-Camcorder
DCR-6600PRO is also suitable to the
4K/3-CCD chip or mega-pixel Digital Camcorders.
(Limited zoom capability)
A LIST OF ADAPTERS for your Camcorder filter
thread sizes |
 |
|
|
Best to use at most wideangle zoom setting.
The original Raynox adapters are designed and made to suit the best
physically and optically to the DCR-6600PRO lens to obtain the optimum
image quality like the pictures shown in our website. When the adapters
of other make were used with Raynox DCR-6600PRO lens, the picture image
quality could be slightly deteriorated, especially around the corners.
● Remote control function and internal video light/Flash may not work properly with conversion lens attached.
● The specifications and cosmetic designs may change without a notice.
● Screw-thread pitch size is 0.75mm unless specified.
●Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image.
●All of Raynox conversion lenses are proudly made in Japan. At our owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.
●The lens is neither made for dust-free nor moisture/water-proof.
