| * 15 models are compatible with HDR-CX110/150/115E/116E/155E, HDR-XR150/XR155E AVCHD Camcorders |
|
|
|
|||||
|
|||||||
|
||||||

| ||||||||||||||||||
   Click lens for actual comparison images.   The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably. |
HDP-7700ES High Definition Super-Telephoto conversion Lens 3.0x Finally, we are able to introduce an ultimate telephoto lens of 3.0 times high powered yet constructed in compact measurements of 92mm length (without Lens Shade) x 58mm outside diameter (at the largest). Thanks to the State-of-the-art lens designing formula developed here in Tokyo Lab, the new 3-group/5-element construction of high index optical glasses reached up to a high image standard of 220 lines/mm resolution power at center (MTF30%) with three times high powered telephoto magnification. It never reached before. Adding the lens on SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras makes it possible to shoot an ultra telephoto picture like the one taken with a 3225mm focal length lens, equivalent in 35mm format. It is necessary to mount RA3730 adapter ring (included accessory) when mounting the lens on the SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras. |
|||||||||||||||||
Magnification: Nominal 3.0x |
||||||||||||||||||
| Comparison movie taken with the HDP-7700ES on or without at the same distance (16:9 Wide mode - Taken with SONY HDR-HC7 HDVcam）  |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||

|
||||||||||||||||||
  Click lens for actual comparison images.  HD-2200PRO-LE+(Plus)  Weight: 37g.(1.3oz) The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably. |
HD-2205PRO/HD-2200PRO-LE+(Plus)(Black model) High Definition 2.2x Telephoto Conversion Lens The model HD-2205PRO/HD-2200PRO-LE+(Plus) High-Definition Super Telephoto Conversion lens is made of the hi-index coated optical glass elements with new concept of lens designing using two-group/four-element lens formula. This new concept of lens designing made it possible to achieve an amazing high definition Telephoto lens of the 200 lines/mm resolution power at center (MTF30%). Adding the lens on SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras makes it possible to shoot an ultra telephoto picture like the one taken with a 2330mm focal length lens, equivalent in 35mm format. It is necessary to mount RA3730 adapter ring (included accessory) when mounting the lens on the SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras. |
|||||||||||||||||
Magnification: Nominal 2.2x Actual 2.17x/Diagonal, 2.17x/Horizontal Lens construction: 2G/4E Optical coated glass elements Minimum focusing distance: 4.5m/2.5m(Tele-macro mode) Effective zooming without vignetting: 9x - 25x zoom Front filter size: 55mm Mounting threads: 37mm Size/Weight: 76 x 59mm/105g(3.7oz) Accessories included: LS-055 Lens shade, Lens caps, Lens pouch, 5-adapter rings 27mm/30mm/30.5mm/34mm/43mm filter size. LS-055 Lens shade is included with HD-2205PRO and HD-2200PRO-LE+(Plus). Specifications |
||||||||||||||||||
|
||||||||||||||||||
|
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||

|
||||||||||||||||||
 Click camera for actual comparison images.  |
HD-5050PRO/HD-5050PRO-LE High Definition 0.5x Wideangle Conversion Lens The model HD-5050PRO/HD-5050PRO-LE Super Wideangle conversion lens is designed to broaden the angle of view, including 100% more area in the picture, when attached to the lens of HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E High Definition camcorder. Its compatible with up to 10x zoom area and stays in focus. How to mount it onto the camera: Before mounting the 0.5x lens on the camera, first remove the adapter ring RA3737 originally set, and screw in the RA3730 ring which comes with the 0.5x lens as accessories. Then mount the lens onto the SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras. |
|||||||||||||||||
Magnification: Nominal 0.5x Actual 0.5x/Diagonal,0.53x/Horizontal Lens construction: 3G/4E Optical coated glass elements Minimum focusing distance: 1cm Effective zooming with conversion lens on: 1x - 10x zoom Front filter size: 62mm Mounting threads: 37mm Size/Weight: 40 x 66mm/110g(3.9oz) Accessories included: Lens caps, Lens case, 6-adapter rings 27mm/30mm/30.5mm/34mm/37mm/43mm filter size. It will start increasing the color aberration when zoomed toward the telephoto end beyond 10-time range with the 0.5x lens on. It still shows some color aberration at the telephoto end even under the bright lighting condition. The photo here was actually taken with the 0.5x lens on set at 25-time zoom range. Specifications |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||

| ||||||||||||||||||
 Click camera for actual comparison images.   The lens shade will cut an unwanted light beam, and it prevents flare and ghost image effect considerably.
|
HD-3035PRO High Definition Semi-Fisheye Conversion Lens 0.3x The model HD-3035PRO Semi-Fish Eye conversion lens is designed to broaden the angle of view, including 180% more area in the picture, when attached to the lens of Sony HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E High Definition Camcorders. The HD-3035PRO has achieved an amazing high definition standard of 520 lines/mm resolution power at center (MTF30%) in the Semi-Fish Eye formula. It is necessary to mount RA3730 adapter ring (included accessory) when mounting the lens on the SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras. |
|||||||||||||||||
Magnification: Nominal 0.3x |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||

| ||||||||||||||||||
 Click camera for actual comparison images. |
HD-6600PRO-37 High Definition
Wideangle Conversion Lens 0.66x The lens is made of hi-index optical glasses, 3-group/3-element, fully coated for non-distortion(-1.3%) and sharp images. It's an ideal accessory lens for professionals and advanced amateurs shooting in tight place. It is necessary to mount RA3730(with knobs) adapter ring (sold separately from us) when mounting the lens on the SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras. |
|||||||||||||||||
Magnification: Nominal 0.66x Actual 0.66x/Diagonal,0.66x/Horizontal Lens construction: 3G/3E Optical coated glass elements Minimum focusing distance: 1cm Effective zooming with conversion lens on: 1x - 12x zoom Front filter size: 72mm Mounting threads: 37mm Size/Weight: 43 x 76mm/175g(6.2oz) Accessories included: Lens caps, Lens case. It will start increasing the color aberration when zoomed toward the telephoto end beyond 13-time range with the 0.66x lens on. It still shows some color aberration at the telephoto end even under the bright lighting condition. The photo here was actually taken with the 0.66x lens on set at 25-time zoom range. Specifications |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||
  |
||||||||||||||||||
 Click camera for actual comparison images. |
DCR-732/DCR-731 lens broadens an angle of view 37% more than the original camera
lens gets. The lens is made of high index optical glass elements which obtain the maximum resolution power of 375 lines/mm at center (MTF30%), It's compatible with whole zoom area and stays in focus. It is necessary to mount RA5237B adapter ring (Included in DCR-732&DCR-731) + RA3730(with knobs) adapter ring (sold separately from us) when mounting the lens on the SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras. There is no difference in the quality of lens between DCR-732 and DCR-731. |
|||||||||||||||||
Magnification: Nominal 0.7x Actual 0.71x/Diagonal, 0.75x/Horizontal Lens construction: 2G/2E Optical coated glass elements Minimum focusing distance: 1cm Effective zooming with conversion lens on: 1x - 10x zoom Front filter size: None Mounting threads: 52mm Size/Weight: 29 x 66mm/130g(4.6oz) Accessories included in DCR-732: 3-Adapter rings, Lens pouch, Lens caps, Instruction manuals. Accessories included in DCR-731: 3-Adapter rings, Lens pouch, Lens caps, Instruction manuals. Specifications |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||
|
||||||||||||||||||
|
QC-707 INSTA-WIDE Wideangle Attachment, 0.7x |
|||||||||||||||||
Magnification: Nominal 0.7x Actual 0.7x/Diagonal Lens construction: 1G/1E Optical coated glass elements Minimum focusing distance: 1cm Effective zooming with conversion lens on: 1x - 4x zoom Front filter size: None Mounting threads: 27-37mm Universal mount Size/Weight: 13 x 50mm/28g(1oz) Accessories included: Lens porch. |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||
|
||||||||||||||||||
 Click camera for actual comparison images. |
QC-505 INSTA-WIDE Super Wideangle Attachment, 0.5x Attaches instantly to your camcorder lens at Wideangle setting to create an extra wideangle view. Ideally suited in shooting in limited space indoors. The Snap-on universal mount is for 27-37mm filter sizes. *Set the camera in AUTO mode while the lens is attached. |
|||||||||||||||||
Magnification: Nominal 0.5x |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||
|
||||||||||||||||||
 Click camera for actual comparison images. |
QC-303 INSTA-WIDE Semi-Fisheye |
|||||||||||||||||
Magnification: Nominal 0.3x Actual 0.3x/Diagonal Lens construction: 1G/1E Optical coated glass elements Minimum focusing distance: 1cm Effective zooming with conversion lens on: 1x - 2x zoom Front filter size: None Mounting threads: 27-37mm Universal mount Size/Weight: 13 x 50mm/40g(1.4oz) Accessories included: Lens porch. 16:9 ratio max. Wideangle: No vignetting in under scanning mode and still image mode 4:3 mode max. Wideangle: It shows vignetting(darkening corners of image) in 4:3 video & still image mode. |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||

| ||||||||||||||||||
 Click camera for actual comparison images.   |
MSN-202 Super Macro Conversion Lens The combination of MSN-202 and SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E makes it easy to capture a tiny object like 1.5mm width for a frame-filling enlarged close-up image from the distance of 32mm to the object at the maximum telephoto position. It is necessary to mount RA3730 adapter ring (sold separately from us) when mounting the lens on the SONY HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E AVCHD cameras. |
|||||||||||||||||
| Magnification: 25-Diopter Lens construction: 3G/4E Optical coated glass elements Smallest field size: 1.5mm in maximum telephoto position Effective zooming without vignetting: 3x - 25x zoom Front filter size: None Mounting threads: 37mm Size/Weight: 22 x 42mm/60g(2.1oz) Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals. |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||
| ||||||||||||||||||
 Click camera for actual comparison images. |
MSN-505 Super Macro Conversion Lens |
|||||||||||||||||
| Magnification: 32-Diopter Lens construction: 3G/4E Optical coated glass elements Smallest field size: 1.2mm in maximum telephoto position Effective zooming without vignetting: 4x - 25x zoom Front filter size: None Mounting threads: 37mm Size/Weight: 26 x 42mm/86g(3oz) Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals. |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||

|
||||||||||||||||||
 |
PFR-030MC Lens Protector Filter The filter is designed to protect your valuable HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E High Definition Camcorder lens from finger prints, dust and other dirt or scratches. The multi-layer coated surfaces will help maintain the original optical performance of your camera. |
|||||||||||||||||
| Mounting threads: 30mm Coatings: Multi-Layer Coated. |
||||||||||||||||||
| PAGE TOP | ||||||||||||||||||
● The cosmetic design may change without a prior notice. There will be no reduction of light value when these conversion lenses are attached on the camera's lens(Except DCR-150, DCR-250, MSN-202, MSN-505 macro lenses.) ● When a telephoto conversion lens is mounted on the high powered zoom camera such as Sony HDR-CX110, CX150, CX155E, CX115E, CX116E, HDR-XR150, XR155E camcorders, the color aberration or other nature of aberration will be increased, to an acceptable degree or beyond. Please make sure to study it with the actual photos taken and shown before purchasing the lens. ● Depending upon the condition of shooting, especially when the lighting is not bright enough, there may be possibility of creating a flare effect which reduces the image quality. When the conversion lens is attached, please make sure that the object is under the bright condition. ● Raynox telephoto conversion lenses are designed to use at maximum Telephoto position of camera's zoom lens, unless specified otherwise. ● Raynox wideangle conversion lenses are designed to use at maximum wideangle position of camera's zoom lens unless specified otherwise. ● Remote control function may not work properly with conversion lens attached. ● Internal video light/flash may not function with conversion lens or filter attached. ● When using the zoom-compatible wide angel lens at the telephoto end of camera lens, it must be done under a bright lighting environment, not indoor or poor lighting condition. Otherwise, it will reduce the image quality. ● An extra caution must be paid to protect the sticking out long lens by hands in carrying around and using the camera with a telephoto lens on. ● To protect the camera from an accidental damage please remove the Conversion Lens before moving the camera and Do not carry around the camera with the Conversion lens attached. ● Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image. ● The lens is neither made for dust-free nor moisture/water-proof. ● All of Raynox conversion lenses are proudly made in Japan. At our wholly owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.
|
||||||||||||||||||
