PFR-025MC Lens Protector Filter for 25mm size
The filter is designed to protect your valuable DCR-HC20/HC30/HC40, DCR-PC109/109E
DV Camcorder lens from air pollution or scratches. The multi-layer coated
surfaces will help maintain the original optical performance of your camera.
The PFR-025MC is also compatible with DCR-DVD101 and DCR-DVD201 DVD Camcorders.
Thread size: 25mm Pitch0.75
Coatings: Multi-Layer Coated.
|
 |
|
|
Click for comparison image |
 |
Click for comparison image |
HD-2205PRO High-Definition
Super Telephoto Conversion lens
The lens is made of the high index coated optical glass elements with new
concept of lens designing using two-group/four-element lens formula. This
new concept in designing the lens made it possible to achieve an amazing
high definition Telephoto lens of the 200 lines/mm resolution power at center (MTF30%)
The HD-2200PRO is an ideal item for over mega-pixel incorporated Mini-Digital
Camcorder and DVDCAM.
(1260KB)
(1700KB)
Raynox lens shade: model LS-055(Sold separately)
Weight: 37g.(1.3oz) |
HD-2205PRO-LE(Black version)
(Available in limited countries.)
The lens is made of the high index coated optical glass elements with new
concept of lens designing using two-group/four-element lens formula. This
new concept in designing the lens made it possible to achieve an amazing
high definition Telephoto lens of the 200 lines/mm resolution power at center (MTF30%)
The HD-2200PRO is an ideal item for over mega-pixel incorporated Mini-Digital
Camcorder and DVDCAM.
(650KB)
(1400KB)
|
|
|
|
Click for comparison image |
|
Click for comparison image |
DVR-2020 2.0x Telephoto Conversion
By adding the lens to the front of your camcorder
lens, it extends the focal length and makes
distant objects appear larger and closer
without having to move closer. The optical
magnification does not spoil the image quality
while it does with digital zooming system.
37mm mounting threads. 5-adapter rings 27mm/30mm/30.5mm
/43mm/49mm included.
Nominal 2.0x(Actual 2.02x). Size:54mm x 51mm
68g.
Front filter size: 49mm
Specifications
(630KB)
It is necessary to mount RA3725 adapter ring when mounting the lens on the DCR-HC20/HC30/HC40, DCR-PC109/109E.
RA3725 adapter ring is Not Included. |
HD-5000PRO 0.5x
Super-Wideangle Conversion Lens
The HD-5000PRO is made of the high-index optical glass elements with new
concept of lens designing using three-group/four-element lens formula.
This new concept in designing the lens made it possible to achieve an amazing
high definition wideangle lens of the 600 lines/mm resolution power at
center(MTF30%).
Front filter size: 62mm
Mounting threads: 37mm
5-adapter rings are included for 27mm/ 30mm/ 30.5mm/ 37mm/ 43mm filter size Camcorders.
Specifications
It is necessary to mount RA3725 adapter ring when mounting the lens on the DCR-HC20/HC30/HC40, DCR-PC109/109E.
RA3725 adapter ring is Not Included.
|
|
|
|
Click for comparison image
|
|
Click for comparison image
|
HD-3035PRO 0.3x
Semi-Fish Eye Conversion Lens
The model HD-3035PRO Semi-Fish Eye conversion lens is designed to broaden
the angle of view, including 180% more area in the picture, when attached
to the lens of Mini-DVCAM.
Compatible with DCR-HC20/HC30/HC40, DCR-PC109/109E. It's compatible with
up to 6x zoom area and stays in focus. I
The HD-3035PRO has achieved an amazing high definition standard of 520 lines/mm resolution power at center(MTF30%) in the Semi-Fish Eye formula.
Front filter size: None
Mounting threads: 37mm
5-adapter rings are included for 27mm/ 30mm/ 30.5mm/ 34mm/ 37mm/ 43mm filter
sized Camcorders.
Specifications
It is necessary to mount RA3725 adapter ring when mounting the lens on the DCR-HC20/HC30/HC40, DCR-PC109/109E.
RA3725 adapter ring is Not Included with HD-3030PRO.
|
DVM-700 Ultra-Compact Wideangle Lens, 0.7x
It is made of metal barrel with mounting
threads of 30mm, and the lens comes with
2adapter rings, 27mm and 30.5mm. It could
be used as permanently attached for convenient
wide coverage video shooting.
30mm mounting threads. 2-adapter rings 27mm/30.5mm
included.
Nominal 0.7x(Actual 0.66x/diagonal).
Size/Weight: 43mm x 22mm 40gr
It is necessary to mount RA3025 adapter ring when mounting the lens on the
DCR-HC20/HC30/HC40, DCR-PC109/109E.
RA3025 adapter ring is Not Included.
Production discontinued. Feb-2009. |
|
|
|
Click for comparison image
|
|
Click for comparison image |
DVR-5000 Super Wideangle Lens, 0.5x
It widens your angle of view 100%, including more area in your picture.
And the lens provides wide, panoramic shots outdoors, and allows shooting
in limited space indoors. The DVR-5000 Wideangle lens is made with an acceptable
good optical quality for general use but not good enough for using with
the highend mega-pixel CCD camcorder, especially for the purpose of getting
a still image or reproduction at the High Definition monitor. For these, we
recommend to use our Raynox HD-5000PRO 0.5x Wideangle lens.
37mm mounting threads. 3-adapter rings 27mm/30mm/30.5mm
included.
It is necessary to mount RA3725 adapter ring when mounting the lens on the DCR-HC20/HC30/HC40, DCR-PC109/109E.
RA3725 adapter ring is Not Included. |
MSN-202 MacroScan Close-up Lens
The combination of MSN-200 and DCR-HC20/HC30/HC40, DCR-PC109/109E DVCAM's
display panel makes it easy to capture a tiny object like 3mm x 2.3mm size
for a frame-filling enlarged close-up image from the distance of 20mm to
the object at maximum telephoto position.
Magnification: 6x compare to camera's maximum wide macro image size.
Lens construction: 3G/4E Optical coated glass elements Mounting threads
: 37mm
Front filter size: None
Size/Weight: 42 x 22mm/60g
It is necessary to mount RA3725 adapter ring when mounting the lens on the DCR-HC20/HC30/HC40, DCR-PC109/109E.
RA3725 adapter ring is Not Included.
CAMERA STAND KS-2000 FOR MACRO IMAGING |
|
|
|
Click for comparison image |
|
|
MSN-505 Super MacroScan Close-up Lens
With MSN-500 Super Macro lens attached, the camera captures an intricate
tiny object like 2mm x 1.5mm for a frame-filling enlarged close-up image
from the distance of 10mm to the object at the maximum telephoto position.
Magnification: 9x compare to camera's maximum wide macro image size.
Lens construction: 3G/4E Optical coated glass elements Mounting threads
: 37mm
Front filter size: None
Size/Weight: 42 x 25mm/86g
It is necessary to mount RA3725 adapter ring when mounting the lens on the DCR-HC20/HC30/HC40, DCR-PC109/109E.
RA3725 adapter ring is Not Included.
CAMERA STAND KS-2000 FOR MACRO IMAGING |
CAMERA STAND KS-2000 FOR MACRO IMAGING
A camera stand with built-in light source and height adjustable camera
mount.
|
|
|
|
|
RA3725 Adapter ring
Especially designed to mount Raynox 37mm mounting size lenses onto 25mm
filter threads of DCR-HC20/HC30/HC40, DCR-PC109/109E DVCAM.
The RA3725 is not compatible with SONY DCR-DVD101 or 201 DVDCAM.
Go to other adapters.
|
|
|
|
●The cosmetic designs may change without prior notice.
●Remote control function and internal video light/Flash may not work properly with conversion lens attached.
●Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image.
●All of Raynox conversion lenses are proudly made in Japan. At our owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.
●The lens is neither made for dust-free nor moisture/water-proof.
|
