Raynox High Definition conversion lenses for Panasonic LUMIX DMC-FZ100, DMC-FZ48, DMC-FZ45, DMC-FZ43 Digital Cameras


* 6 models are compatible with Lumix DMC-FZ150/FZ100/FZ48/FZ45/FZ40 Hybrid Digital Cameras


Captures an amazing telephoto view in High Definition quality

	Click camera for actual comparison images.	With LS-082 lens shade

DCR-2025PRO 2.2x High Definition Telephoto Conversion Lens DCR-2025PRO lens extends the focal length of LUMIX DMC-FZ150, FZ100, FZ48, FZ45, FZ40 camera zoom lenses to 1320mm* Super telephoto ! It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula. 260 lines/mm resolution power at center (MTF30%) For mounting Raynox DCR-2025PRO lens on LUMIX DMC-FZ150, FZ100, FZ48, FZ45, FZ40 cameras, it’s necessary to have the Panasonic original DMW-LA5 Lens Adapter and Raynox RA6255** adapter ring mounted. 35mm film equivalent(4:3)-24x optical zoom. * Included in original factory package. Magnification: Nominal 2.2x, Actual 2.2x/Diagonal, 2.2x/Horizontal Lens construction: 2G/4E Optical coated glass elements Minimum focusing distance: 4.5m(AF macro mode) Effective zooming without vignetting: 20x - 24x zoom Front filter size: 82mm Mounting threads: 62mm Size/Weight: 123 x 85mm/275g(9.7oz) Accessories included: LS-082 Lens shade, Lens caps, Lens pouch, 4-adapter rings 43mm/52mm/55mm/58mm filter size. Specifications
The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably.		Raynox lens shade: model LS-082 Weight: 69g.(2.4oz)
		PAGE TOP

Enhances and creates the superb image quality in High Definition shooting
Click camera for actual comparison images.	DCR-1541PRO 1.54x High Definition telephoto Conversion Lens DCR-1541PRO lens extends the focal length of Lumix DMC-FZ150, FZ100, FZ48, FZ45, FZ40 camera zoom lenses to 924mm telephoto! (35mm film equivalent) It's a completely new high definition lens made of the high index optical lens with a 2-group /4-element formula. 340 lines/mm resolution power at center (MTF30%) For mounting Raynox DCR-1541PRO lens on LUMIX DMC-FZ150, FZ100, FZ48, FZ45, FZ40 cameras, it’s necessary to have the Panasonic original DMW-LA5 Lens Adapter and Raynox RA5255B** adapter ring mounted. 35mm film equivalent. * Included in original factory package.
	Magnification: Nominal 1.54x Actual: 1.54x / Diagonal, 1.54x / Horizontal Minimum focusing distance: 2.5m(AF macro mode) Zoom capability: 11x-24x Lens construction: 2G/4E Optical coated glass elements Mounting threads: 52mm Front filter size: 67mm Size/Weight: 71 x 67mm/240g Accessories included: Lens caps, Lens pouch, 3-adapter rings 37mm/43mm/55mm filter size. Specifications
	PAGE TOP

Explore a world you never knew existed
With Panasonic DMW-LA5 lens adapter Without Panasonic DMW-LA5 lens adapter Click camera for actual comparison images.	DCR-150 Macro Conversionlens You can simply "Snap On" DCR-150 Macro lens onto the filter threads of DMW-LA5 Lens Adapter.(Shooting distance from the object ; 210mm in maximum telephoto macro mode.) For mounting Raynox DCR-150 lens on LUMIX DMC-FZ150, FZ100, FZ48, FZ45, FZ40 cameras, it’s recommended to have the Panasonic original DMW-LA5 Lens Adapter mounted. Please do not use zoom function when shooting without a DMW-LA5 lens adapter installed.
	Magnification: 4.8-Diopter Lens construction: 2G/3E Optical coated glass elements Smallest field size: 12.2mm in maximum telephoto position Effective zooming without vignetting: 8x -24x zoom(with DMW-LA5) Front filter size: 49mm Mounting threads: 43mm Size/Weight: Lens only - 18 x 53mm/50g(1.8oz) Accessories included: Lens caps, Lens case, Universal adapter UAC2000. Specifications
	PAGE TOP

Explore a world you never knew existed
With DMW-LA5 lens adapter Without DMW-LA5 lens adapter Click camera for actual comparison images.	DCR-250 Super Macro Conversion Lens You can simply "Snap On" DCR-250 Macro lens onto the filter threads of DMW-LA5 Lens Adapter. The shooting distance to the object is about 109mm and the picture size would be 7.3mm width in 4:3 mode. For mounting Raynox DCR-250 lens on LUMIX DMC-FZ150, FZ100, FZ48, FZ45, FZ40 cameras, it’s recommended to have the Panasonic original DMW-LA5 Lens Adapter mounted. Please do not use zoom function when shooting without a DMW-LA5 lens adapter installed.
	Magnification: 8-Diopter Lens Construction: 2G/3E Optical coated glass elements Smallest field size: 7.3mm in maximum telephoto position Effective zooming without vignetting: 14x -24x zoom(with DMW-LA5) Front filter size: 49mm Mounting threads: 43mm Size/Weight: Lens only - 18 x 53mm/60g(2.1oz) Accessories included: Lens caps, Lens case, Universal adapter UAC2000. Specifications
	PAGE TOP

Turn your Hybrid camera into a powerful microscope
With DMW-LA5 lens adapter Without DMW-LA5 lens adapter Click camera for actual comparison images.	MSN-202 Super Macro Conversion Lens You can simply "Snap On" MSN-202 Super Macro lens onto the lens filter threads.(52-67mm) by using a universal mount UAC3500 and it will be able to take macro images with minimum distortion at the maximum telephoto position of Lumix DMC-FZ150, FZ100, FZ48, FZ45, FZ40 camera. (Shooting distance from the object ;32mm at infinity focusing position.) For mounting Raynox MSN-202 lens on LUMIX DMC-FZ150, FZ100, FZ48, FZ45, FZ40 cameras, it’s recommended to have the Panasonic original DMW-LA5 Lens Adapter mounted. Please do not use zoom function when shooting without a DMW-LA5 lens adapter installed.
	Magnification: 25-Diopter Lens construction: 3G/4E Optical coated glass elements Smallest field size: 2.3mm in maximum telephoto position Effective zooming without vignetting: 17x -24x zoom(with DMW-LA5) Front filter size: None Mounting threads: 37mm Size/Weight: 22 x 42mm/60g(2.1oz) Accessories included: Lens caps, Lens case, Universal adapter UAC3500.
	PAGE TOP

Turn your Hybrid camera into a powerful microscope
With DMW-LA5 lens adapter Without DMW-LA5 lens adapter Click camera for actual comparison images.	MSN-505 Ultra Macro Conversion Lens With MSN-505 Super Macro lens attached, the camera captures an intricate tiny object like 1.8mm width for a frame-filling enlarged close-up image from the distance of 18.5mm to the object at the maximum telephoto position. For mounting Raynox MSN-505 lens on LUMIX DMC-FZ150, FZ100, FZ48, FZ45, FZ40 cameras, it’s recommended to have the Panasonic original DMW-LA5 Lens Adapter mounted. Please do not use zoom function when shooting without a DMW-LA5 lens adapter installed.
	Magnification: 32-Diopter Lens construction: 3G/4E Optical coated glass elements Smallest field size: 1.8mm in maximum telephoto position Effective zooming without vignetting: 23x - 24x zoom(with DMW-LA5) Front filter size: None Mounting threads: 37mm Size/Weight: 26 x 42mm/86g(3oz) Accessories included: Lens caps, Lens case, Universal adapter UAC3500.
	PAGE TOP

● The cosmetic design may change without a prior notice.
● There will be no reduction of light value when these conversion lenses are attached on the camera's lens(Except DCR-150, DCR-250, MSN-202, MSN-505 macro lenses.)
● Depending upon the condition of shooting, especially when the lighting is not bright enough, there may be possibility of creating a flare effect which reduces the image quality. When the conversion lens is attached, please make sure that the object is under the bright condition.
● Raynox telephoto conversion lenses are designed to use at maximum Telephoto position of camera's zoom lens, unless specified otherwise.
● Remote control function may not work properly with conversion lens attached.
● Internal video light/flash may not function with conversion lens attached.
● AF Assist mode may not function properly when the conversion lens is attached.
● All numerical scales and magnification being presented on this page may change depending on the number of pixels on the camera setting.
● An extra caution must be paid to protect the sticking out long lens by hands in carrying around and using the camera with a telephoto lens on.
● To protect the camera from an accidental damage please remove the Conversion Lens before moving the camera and Do not carry around the camera with the Conversion lens attached.
● Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image.
● The lens is neither made for dust-free nor moisture/water-proof.
● All of Raynox conversion lenses are proudly made in Japan. At our wholly owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.
