* 15 models are compatible with HDR-HC9, HDR-HC7/7E, HDR-HC5/HC5E, HDR-UX7/UX7E, HDR-UX5/UX5E, HDR-CX7/CX7EK, HDR-CX7KE/CX7E/CX7K, HDR-CX6EK, HVR-HD1000E/HD1000J/HD1000N/HD1000P/HD1000U

Captures a super panoramic view in high-definition image quality


HDP-2800ES High Definition
Diagonal Fisheye conversion Lens 0.28x

The HDP-2800ES lens is a conversion lens for capturing an ultra wide angle image in using with the High Definition Digital camcorder. The lens is particularly designed to be in focus through the whole zoom range of up to 5x*. The lens is made of the high index optical glass in 3-group/3-element formula, and it's made in compact size and light weight. It achieved a high resolution power of 475 lines/mm at center (MTF30%). Mounting on the wide-angle lens of f=26mm or less (35mm film equivalent) focal length, it will be possible to shoot the scene of 180-degree diagonal**.

The two adapter rings of 37mm and 43mm come with the lens in the original factory package for use with the same filter sized lenses.

* The 5x zoom compatibility mentioned above is based on the actual test data made with the under 10x zoom HD camcorder, and depending upon the model of camera lens you use, effective zooming may become less than 5x. For finding the suitable camera models please visit our Raynox Home Page and see the Cross Reference Table.
** A designing calculation figure.


Specifications
  PAGE TOP




Click lens for actual comparison images.





The lens shade will cut an unwanted light beam, and it prevents flare and ghost image effect considerably.
HDP-7700ES High Definition
Super-Telephoto conversion Lens 3.0x

Finally, we are able to introduce an ultimate telephoto lens of 3.0 times high powered yet constructed in compact measurements of 92mm length (without Lens Shade) x 58mm outside diameter (at the largest). Thanks to the State-of-the-art lens designing formula developed here in Tokyo Lab, the new 3-group/5-element construction of high index optical glasses reached up to a high image standard of 220 lines/mm resolution power at center (MTF30%) with three times high powered telephoto magnification. It never reached before.

The Lens Shade and 5-adapter rings come with the lens as a standard accessory.

With the HDP-7700ES lens attached, there will be no influence on F number of the master lens.
Magnification: Nominal 3.0x
Actual 3.0x/Diagonal, 3.0x/Horizontal
Lens construction: 3G/5E Optical coated glass elementsz
Minimum focusing distance: 10m/6m(Tele-macro mode)
Effective zooming without vignetting: 9x - 10x zoom
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 92 x 58mm/218g(7.68oz)

Accessories included: LS-055 Lens Shade, Lens caps, Lens pouch, 5-adapter rings 27mm/30mm/30.5mm/34mm/43mm filter size.
Specifications

Comparison movie taken with the HDP-7700ES on
or without at the same distance
(16:9 Wide mode - Taken with SONY HDR-HC7 HDVcam)


PAGE TOP








Click camera for actual comparison images.



HD-2200PRO-LE+(Plus)(Black model)




Weight: 37g.(1.3oz)

The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably.

HD-2205PRO High Definition
2.2x Telephoto Conversion Lens

The model HD-2205PRO High-Definition Super Telephoto Conversion lens is made of the hi-index coated optical glass elements with new concept of lens designing using two-group/four-element lens formula. This new concept of lens designing made it possible to achieve an amazing high definition Telephoto lens of the 200 lines/mm resolution power at center (MTF30%).

Magnification: Nominal 2.2x
Actual 2.17x/Diagonal, 2.17x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 4.5m/2.5m(Tele-macro mode)
Effective zooming without vignetting: 9x - 10x zoom
Front filter size: 55mm
Mounting threads: 37mm
Size/Weight: 76 x 59mm/105g(3.7oz)

Accessories included: LS-055 Lens shade, Lens caps, Lens pouch, 5-adapter rings 27mm/30mm/30.5mm/34mm /43mm filter size.

LS-055 Lens shade is included with HD-2205PRO and HD-2200PRO-LE+(Plus).

Specifications
VIDEO CLIP 2000KB
VIDEO CLIP 3000KB
Comparison movie taken with the HD-2205PRO on or without at the same distance.
(16:9 Wide ratio)
VIDEO CLIP 2000KB
VIDEO CLIP 3000KB
Comparison movie taken with the HD-2205PRO on or without at the same distance.
(16:9 Wide ratio with 20x Digital zoom)
PAGE TOP






Click camera for actual comparison images.





 Raynox lens shade: model LS-082
Weight: 69g.(2.4oz)


DCR-2025PRO 2.2x
High Quality Telephoto Conversion Lens

DCR-2025PRO lens extends the focal length of SONY HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7zoom lens to 1070mm* Super telephoto !*
It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula. 260 lines/mm resolution power at center (MTF30%)
Model RA6252( included accessory) and RA5237B Raynox adapter ring(sold separately) for 37mm filter size are required for use with the DCR-2025PRO + HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5 cameras.

*35mm film equivalent in 4:3 ratio.
Magnification: Nominal 2.2x
Actual 2.2x/Diagonal, 2.2x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 4.5m/2.5m(Tele-macro mode)
Effective zooming without vignetting: 5x - 10x zoom
Front filter size: 82mm
Mounting threads: 62mm
Size/Weight: 123 x 86mm/275g(9.7oz)

Accessories included: LS-082 Lens shade, Lens caps, Lens pouch, 4-adapter rings 43mm/52mm/55mm/58mm filter size.

Specifications


The lens shade will cut an unwanted light beam, and it reduces flare and ghost image effect considerably.
PAGE TOP








Click camera for actual comparison images.


DCR-1542PRO/DCR-1541PRO 1.54x
HD Telephoto Conversion Lens

DCR-1542PRO/DCR-1541PRO lens extends the focal length of SONY HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7 zoom lens to 750mm telephoto lens!*
It's a completely new high definition lens made of the high index optical lens with a 2-group/4-element formula.
This new concept in designing the lens made it possible to achieve an amazing high definition telephoto lens of the 340 lines/mm resolution power at center (MTF30%), low dispersion and the increased light transmittance at fringe area.
It is necessary to mount RA5237B adapter ring (Included in DCR-1542PRO/DCR-1541PRO) when mounting the lens on the HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5 cameras.
There is no difference in the quality of lens between DCR-1542PRO, DCR-1541PRO and DCR-1540PRO.
RA5237B adapter ring is Not Included in DCR-1540PRO.
*35mm film equivalent in 4:3 ratio.
Magnification: Nominal 1.54x
Actual 1.54x/Diagonal, 1.54x/Horizontal
Lens construction: 2G/4E Optical coated glass elements
Minimum focusing distance: 2.5m/1.5m(Tele-macro mode)
Effective zooming without vignetting: 3x - 10x zoom(16:9 ratio)
Front filter size: 67mm
Mounting threads: 52mm
Size/Weight: 67 x 71mm/240g(8.5oz)
Accessories included in DCR-1542PRO : 3-Adapter rings 37mm/43mm/46mm filter size, Lens pouch, Lens caps, Instruction manuals.
Accessories included in DCR-1541PRO : 3-Adapter rings 37mm/43mm/55mm filter size, Lens pouch, Lens caps, Instruction manuals.
Specifications
PAGE TOP





Click camera for actual comparison images.





The lens shade will cut an unwanted light beam, and it prevents flare and ghost image effect considerably.
(Model LS-03W is included in RAYNOX LS-03W-K
Lens Shade Mask Kit which is sold separately.)
HD-3035PRO/HD-3032PRO High Definition
Semi-Fisheye Conversion Lens 0.3x

The model HD-3035PRO/HD-3032PRO Semi-Fish Eye conversion lens is designed to broaden the angle of view, including 180% more area in the picture, when attached to the lens of HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7 High Definition Camcorders.

The HD-3035PRO/HD-3032PRO has achieved an amazing high definition standard of 520 lines/mm resolution power at center (MTF30%) in the Semi-Fish Eye formula.
Specifications
(There is no quality difference between HD-3035PRO and HD-3032PRO lens.)
Magnification: Nominal 0.3x
Actual 0.34x/Diagonal, 0.44x/Horizontal(4:3ratio)
Lens construction: 2G/2E Optical coated glass elements
Effective zooming with conversion lens on: 1x - 4x zoom
Front filter size: None
Mounting threads: 37mm
Size/Weight: 45 x 70mm/143g(5.0oz)

Accessories included with HD-3035PRO : LS-03W Lens shade mask, Lens caps, Lens case, 5-adapter rings 27mm/30mm/30.5mm/37mm/34mm/43mm filter size.

Accessories included with HD-3032PRO : Lens caps, Lens case, , 5-adapter rings 27mm/30mm/30.5mm/37mm/34mm/43mm filter size.

LS-03W Lens shade mask is included with HD-3035PRO.
LS-03W Lens shade mask is Not included with HD-3032PRO.

Specifications
PAGE TOP






Click camera for actual comparison images.



HD-6600PRO-37 High Definition
Wideangle Conversion Lens 0.66x

The lens is made of hi-index optical glasses, 3-group/3-element, fully coated for non-distortion(-1.3%) and sharp images. It's an ideal accessory lens for professionals and advanced amateurs shooting in tight place.
Mount the lens directly on the 37mm filter threads of HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5.
Magnification: Nominal 0.66x
Actual 0.66x/Diagonal, 0.66x/Horizontal
Lens construction: 3G/3E Optical coated glass elements
Effective zooming with conversion lens on: 1x - 10x zoom
Front filter size: 72mm
Mounting threads: 37mm
Size/Weight: 43 x 76mm/175g(6.2oz)

Accessories included: Lens caps, Lens case.

Specifications
PAGE TOP







Click camera for actual comparison images.


DCR-732/DCR-731 Wideangle Conversion Lens 0.7x
DCR-732/DCR-731 lens broadens an angle of view 37% more than the original camera lens gets. The lens is made of high index optical glass elements which obtain the maximum resolution power of 375 lines/mm at center (MTF30%), It's compatible with whole zoom area and stays in focus.
It is necessary to mount RA5237B adapter ring (Included in DCR-732, DCR-731) when mounting the lens on the HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5 cameras.
There is no difference in the quality of lens between DCR-732 and DCR-731.
Magnification: Nominal 0.7x
Actual 0.71x/Diagonal, 0.75x/Horizontal
Lens construction: 2G/2E Optical coated glass elements
Minimum focusing distance: 1cm
Effective zooming with conversion lens on: 1x - 10x zoom
Front filter size: None
Mounting threads: 52mm
Size/Weight: 29 x 66mm/130g(4.6oz)
Accessories included in DCR-731: 3-Adapter rings, Lens pouch, Lens caps, Instruction manuals.
Accessories included in DCR-730 : Lens pouch, Lens caps, Instruction manuals.

Specifications
PAGE TOP








Click camera for actual comparison images.


HD-7000PRO High Definition
Wideangle Conversion Lens 0.7x

The model HD-7000PRO high definition Wideangle conversion lens is made of the high index optical glass with new concept of lens designing using three-group/three-element lens formula. This new concept in designing the lens made it possible to achieve an amazing high definition wideangle lens of 540 lines/mm resolution power at center (MTF30%).

It is necessary to mount RA5837 adapter ring (sold separately from us) when mounting the lens on the HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7 .
Magnification: Nominal 0.7x
Actual 0.7x/Diagonal, 0.7x/Horizontal
Lens construction: 3G/3E Optical coated glass elements
Effective zooming with conversion lens on: 1x - 10x zoom(16:9 ratio)
Front filter size: 82mm
Mounting threads: 58mm
Size/Weight: 40 x 86mm/314g(11oz)

Accessories included: Lens caps, Lens pouch.

Specifications
PAGE TOP






Click camera for actual comparison images.


HD-5050PRO/HD-5050PRO-LE High Definition
0.5x Wideangle Conversion Lens

The model HD-5050PRO/HD-5050PRO-LE Super Wideangle conversion lens is designed to broaden the angle of view, including 100% more area in the picture, when attached to the lens of HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7 High Definition camcorder. Its compatible with the whole zoom area and stays in focus.
(Both HD-5050PRO and HD-5050PRO-LE are the same lens.)
Magnification: Nominal 0.5x
Actual 0.5x/Diagonal, 0.53x/Horizontal
Lens construction: 3G/4E Optical coated glass elements
Effective zooming with conversion lens on: Full(1x - 10x**) zoom
Front filter size: 62mm
Mounting threads: 37mm
Size/Weight: 40 x 66mm/110g(3.9oz)

Accessories included: Lens caps, Lens case, 6-adapter rings 27mm/30mm/30.5mm/34mm/37mm/43mm filter size.

16:9 ratio max. Wideangle: No vignetting in under scanning mode and still image mode
4:3 mode max. Wideangle: It shows vignetting(darkening corners of image) in 4:3 still ratio

**The lens is made compatible in using with a 10x zoom lens of HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5 cameras However, when zoomed up to the end of the telephoto with the lens on, the image quality of the picture will be lowered except the center area, and the deterioration of resolution power at corners will occur.

Specifications
PAGE TOP







Click camera for actual comparison images.


WMV FILE 3350KB
MPEG-4 4500KB
DCR-5000 Wideangle Conversion Lens 0.5x
Production discontinued - July 2008
DCR-5000 lens broadens an angle of view 100% more of the original camera lens.

It is necessary to mount RA5237B adapter ring (sold separately from us) when mounting the lens on the HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5.

Magnification:Nominal 0.5x
Actual 0.5x/Horizontal, 0.44x/Diagonal
(Limited zoom capability)
Lens construction: 1G/1E Optical coated glass elements
Front filter size: None
Mounting threads: 52mm
Size/Weight: 26 x 90mm/140g(4.9oz)

Accessories included: Lens caps, Lens pouch.

DCR-5000 is designed to focus when the zoom lens is set in 1-2x wideangle position.

Specifications
PAGE TOP






Click camera for actual comparison images
.

DCR-150 Macro Conversion Lens
You can simply "Snap On" DCR-150 Macro lens onto the RA5237B adapter ring. The shooting distance to the object is about 210mm and the picture size would be 19mm width in Tape recoding mode.

It is necessary to mount RA5237B adapter ring (sold separately from us) when mounting the lens on the HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5.
Magnification: 4.8-Diopter
Lens construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 1x-10x zoom(16:9 ratio)
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/50g(1.8oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.

Specifications
PAGE TOP






Click camera for actual comparison images.


DCR-250 High Power Macro Conversion Lens
You can simply "Snap On" DCR-250 Macro lens onto the RA5237B adapter ring. The shooting distance to the object is about 109mm and the picture size would be 10mm width in Tape recoding mode.

It is necessary to mount RA5237B adapter ring (sold separately from us) when mounting the lens on the HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5.
Magnification: 8-Diopter
Lens Construction: 2G/3E Optical coated glass elements
Effective zooming without vignetting: 1x - 10x zoom(16:9 ratio)
Front filter size: 49mm
Mounting threads: 43mm
Size/Weight: Lens only - 18 x 53mm/60g(2.1oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC2000, Instruction manuals.

Specifications
PAGE TOP






Click camera for actual comparison images.


WMV FILE 8900KB
MPEG-4 8400KB
MSN-202 Super Macro Conversion Lens
The combination of MSN-202 and SONY HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7 makes it easy to capture a tiny object like 3mm width for a frame-filling enlarged close-up image from the distance of 32mm to the object at the maximum telephoto position.
Magnification: 25-Diopter
Lens construction: 3G/4E Optical coated glass elements
Image size: 3mm width
Effective zooming without vignetting: 2x - 10x zoom(16:9 ratio)
Front filter size: None
Mounting threads: 37mm
Size/Weight: 22 x 42mm/60g(2.1oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
PAGE TOP






Click camera for actual comparison images.


WMV FILE 8900KB
MPEG-4 8400KB

MSN-505 Super Macro Conversion Lens
With MSN-505 Super Macro lens attached, the camera captures an intricate tiny object like 2mm width for a frame-filling enlarged close-up image from the distance of 18.5mm to the object at the maximum telephoto position.
Magnification: 32-Diopter
Lens construction: 3G/4E Optical coated glass elements
Image size: 2mm width
Effective zooming without vignetting: 3x - 10x zoom(16:9 ratio)
Front filter size: None
Mounting threads: 37mm
Size/Weight: 26 x 42mm/86g(3oz)

Accessories included: Lens caps, Lens case, Universal adapter UAC3500, Instruction manuals.
PAGE TOP





PFR-037MC Lens Protector Filter for HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7
The filter is designed to protect your valuable HDR-HC7/HDR-HC5, HDR-UX7/HDR-UX5, HDR-CX7 High Definition Camcorder lens from air pollution or scratches. The multi-layer coated surfaces will help maintain the original optical performance of your camera.

Thread size: 37mm Pitch0.75
Coatings: Multi-Layer Coated.
PAGE TOP

The cosmetic design may change without a prior notice.
There will be no reduction of light value when these conversion lenses are attached on the camera's lens(Except DCR-150, DCR-250, MSN-202, MSN-505 macro lenses.)
Depending upon the condition of shooting, especially when the lighting is not bright enough, there may be possibility of creating a flare effect which reduces the image quality. When the conversion lens is attached, please make sure that the object is under the bright condition.
Raynox telephoto conversion lenses are designed to use at maximum Telephoto position of  camera's zoom lens, unless specified otherwise.
Raynox wideangle conversion lenses are designed to use at maximum wideangle position of  camera's zoom lens unless specified otherwise.
HD-7000PRO, HD-5050PRO, HD-6600PRO-52/DCR-6600PRO and DCR-730 lenses are made compatible in using with a HC7's 10x zoom lens. However, when zoomed up to the end of the telephoto with the lens on, the image quality of the picture will be lowered except the center area, and the deterioration of resolution power at corners will occur. You can see the actual degree of deteriorated image on the reference picture in our RAYNOX home page. When shooting with a 10-time zoom lens at the telephoto side, please select the bright area of enough lighting. When you are using the wide-angle lens on the zoom lens set at the telephoto end frequently.
Please note that the minimum focusing distance with the HDP-7700ES Lens attached will be approximately 9 times more of the original distance figured at the telephoto end. We recommend to use a sturdy tripod when shooting with HDP-7700ES lens on.
Remote control function may not work properly with conversion lens attached.
Internal video light/flash may not function with conversion lens or filter attached.
To protect the camera from an accidental damage please remove the Conversion Lens before moving the camera and Do not carry around the camera with the Conversion lens attached.
Exposing the conversion lens to a warm atmosphere in an instant way from the cold area may create some dew on and inside the lens. When it happened inside the lens, keep the lens in a dry area till the dew disappear before using. Repeating such may leave dirt spot - (mildew) and affect the image.
The lens is neither made for dust-free nor moisture/water-proof.
All of Raynox conversion lenses are proudly made in Japan. At our wholly owned manufacturing subsidiary, every stage of production is rigorously checked and tested so that the lens elements compensate effectively for astigmatism, distortion and spherical aberration.... for an excellent image quality.


FOR DIGITAL CAMERA FOR VIDEO CAMCORDER MACRO LENS FOR SLR CAMERA PROJECTION LENS ABOUT US
WORLDWIDE CONTACT ENGLISH INDEX HOME

RAYNOX is the registered trademark of Yoshida Industry Co., Ltd. Tokyo. Other brand names and the models are the trademarks of their manufactures or their subsidiaries and may be registered in certain jurisdictions. ©Y.I.C.
